The NDC72CN is compact powerful 1.4” neodymium high frequency compression driver, which features a carbon composite dome with high damped vented suspension, providing high output with very low distortion. The new carbon composite technology reduces breakup modes and ensures excellent Waterfall Response of the driver. These new dome materials provide perfect vocal reproduction with very warm and clean sounding. The neodymium magnet, top and back plates are treated with special high quality epoxy electro-deposition coating, which extremely improves the corrosion resistance of the driver.The voice coil assembly is easily fielded replaceable without soldering. It is designed for a wide variety of applications in high quality, high power professional reinforcement systems and stage monitors.
OBERTONNeodymium
OBERTON NDC72CN
1.4” High Frequency Compression Driver, 2.85” voice coil, 100 W, 111 dB, 8/16 Ohm
| Brand |
OBERTON |
|---|---|
| Condition |
New |
| Power |
100W |
| Tweeter Diameter |
1.4" |
| Magnetic Material |
Neodymium |
Description
KEY FEATURES
- Throat diameter: 1.4″/36 inch/mm
- Impedance: 16 Ohm
- Power Capacity: 100 W
- Program Power Capacity: 200 W
- Frequency Range: 800 Hz – 18 kHz
S P E C I F I C A T I O N S
| Throat diameter | 36 mm (1.4 in.) |
|---|---|
| Nominal impedance | 16 Ohms |
| Minimum impedance | 12.7 Ohms |
| DC resistance | 10 Ohms |
| Power capacity | (1-20 kHz) 100 W |
| Program Power Capacity | (1-20 kHz) 200 W |
| Sensitivity | (1 kHz – 10 kHz) 111 dB/W/m |
| Frequency Range | 800Hz-18 kHz |
|---|---|
| Recommended crossover | 1 kHz or higher 12 dB/oct.min |
| Voice coil diameter | 72 mm (2.85 in.) |
| Diaphragm | Carbon Composite |
| Voice coil material | Copper Clad Aluminium Wire |
| Voice coil former | Kapton |
| Flux density | 1.9 T |
