Digilive is the result of many years of R&D combining Studiomaster’s experience in signal processing. Although ultra compact , Digilive 16 uses the full potential of our digital mixer expertise without compromising any features. All settings can be recalled including, most importantly, the faders, unique in this class of mixers. Full iOS tablet control is also available remotely via the built in Wi-Fi, so you are free to mix away from the desk. Digilive 16 has 12 mic, 12 line inputs and 2 stereo inputs all routable via 16 busses to 8 balanced outputs. Joining them is a host of professional digital interfaces – AES,EBU, SPDiF and two USB. The 1024×600 touch screen makes navigation simple and intuitive. In fact Digilive can be used straight out of the box without the need to read a 100 page manual.
DIGILIVE 16
Introducing the Studiomaster Digilive 16 mixer – a 16 inputs digital audio mixer with large touch screen – everything you need for perfect live mixing.
| Weight | 6 kg |
|---|---|
| Dimensions | 35.7 × 48 × 14.5 cm |
| Brand |
Studiomaster |
| Condition |
New |
Description
Introducing Digilive 16
KEY FEATURES
- 16 input with 16 internal busses
- 12 professional mic input channels
- 9 motorized 100mm faders
- Up to 8 internal effects busses
- 8 configurable ‘smart’ outputs
- 7” high resolution touch screen or full tablet operation
- S/pdif in/out & AES-EBU output
- Real time operation with full featured iOS app
INTELLIGENT USER INTERFACE
- simple to use 1024×600 7” touchsceen with clear and informative graphics
- Clear visual representation of all channel and mixer settings
- Use either touchscreen or encoder to adjust any setting
- 100mm motorized faders, with one touch layer selection
- Solo, mute and channel select buttons for each channel
ADVANCED ALGORITHMS
- 4 band fully parametric EQ
- Each band adjustable between 20Hz and 20kHz
- Variable gain and Q, and ability to save EQ library presets
DYNAMICS & EFFECTS ON EVERY CHANNEL
- Fully adjustable gate and compression
- 4 stereo effects available with reverb, delay, modulation and 31 band graphic EQ
- Simple to use and informative visual representation of effect or dynamic
- Depth and gain reduction metering for accurate adjustment
SMART OUTPUTS
- 16 internal busses with 8 balanced XLR outputs
- Comprehensive routing facilities to maximise mixer flexibility
- Simple and clear selection and routing
MIXING MADE EASY
- Input and output channel metering is clear with the high definition screen
- Both input and output levels clearly displayed
- Pre and post fader metering
RECORDING & PLAYBACK
- Built in media player and recorder
- Playback from either USB
- Record from any smart output
S P E C I F I C A T I O N S
Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.
| MIC Input | 12 channels (8 x XLR / 4 x COMBO XLR / JACK) |
|---|---|
| LINE Input | 2 (Stereo) channels (two 6.5 stereo Jacks, one 3.5 stereo Jack in parallel with one stereo channel) |
| Master output | 2 Left/Right balanced XLR |
| Smart Outputs | 6 assignable balanced XLR |
| Internal busses | 16 |
| Stereo Monitor | 1 TRS Jack output |
| Headphone | 1 TRS Jack output |
| Screen | 7” high definition touch screen |
| Faders | 8 x motorized 100 mm faders + 1 x motorized 100mm fader for L/R mix |
| Operating System | Android system |
| Sample Frequency | 48 KHz |
|---|---|
| AD/DA | 192KHz, 24-bit |
| DSP | 40-bit float point, SHARC processor |
| iPad Remote control | Yes |
| Effects | up to 8 assignable effect modules (reverb,modulation,delay, 31band GEQ with RTA) |
| AES/EBU | Output (XLR) |
| S/PDIF | Input / Output (RCA phono) |
| USB Interface | 2 for playback/recording, scene storage and system updates |
| Network | yes via WIFI external module |
| Power | 90-240V ~ 50/60Hz power supply 12VDC output |
| Dimension (WxHxD) | 357x480x145mm |
Reviews (0)
About Studiomaster
Studiomaster is a British manufacturer of mixing consoles, power amplifiers, speaker cabinets and other professional audio equipment. Studiomaster was established in the 1970s and the brand name is now under the umbrella of Studioking Limited based in the UK.
